HD Antifreeze Coolant Suitable for All Makes and Models That Require Nitrite FREE Formulation
Service Life 1,200,000 kms or 15,000 hours*
Suitable for all engines that required a Nitrite FREE formulation
Suitable for CAB fabricated cooling system components
Provides excellent protection for aluminium and all other engine metals
Protects against liner pitting and corrosion
Specifically formulated for 2014 engines or newer that require Nitrite FREE coolants
Compatible with all brands Nitrite FREE OAT coolants
Approved by Cummins to meet CES14439 & CES14636
Approved by Detroit Diesel to meet 93K217
Suitable for all makes and models of truck and commercial equipment and machinery that DOES NOT require a non 2-EH formulation and has an aluminium cooling system. The Nitrite FREE formulation is suitable for CAB (controlled atmosphere brazing) fabricated cooling system components and provides maximum liner protection against pitting and corrosion. Provides 750,000 Miles (1.2 million kms ) 15,000 hour Service Life * and is suitable for all Fleet and off road applications including light Commercial.
Nitrite Free is OE factory fill on following
Cummins 2014 on : Detroit 2015 on : Volvo & Mack 2017 on
HD Compatibility Chart
Nitrite FREE Organic Acid Technology
Prestone Command® HD Concentrate and 50/50 Antifreeze/Coolant are Nitrite FREE Organic Acid Technology for use and compatible with ANY OAT Extended Life Heavy Duty antifreeze/coolant in ANY diesel-powered commercial vehicle engine or stationary engine. Its advanced, patented formulation is a concentrated blend of premium long-lasting inhibitors designed to provide up to 1,200,000 kms/15,000 hours* of protection against temperature extremes, rust, corrosion, scale and premature water pump failure.
* To achieve mileage claims: Cooling system required to be flushed and filled with 50/50 mixture of Command and high quality water. Only top off with Command as / if required. Use new coolant if replacing a cooling system part.
Product Specification
CONCENTRATE TECHNICAL DATA
Composition by Weight Typical Values
Antifreeze/Coolant Concentrate: 96.7%
Total Water: 3.3%
Dyes: Trace
Properties Typical Values
Color: YELLOW
Odor: Characteristic
Ash Content: 1.5% by weight
pH at 50 vol%:: 8.2-8.8
Reserve Alkalinity: 5.5 mL
Density at 15°C, g/mL: 1.1159
Freezing Point 50 vol%: -34°F (-37°C)
Boiling Point at 50 vol%: +226°F (+108°C)
Foam Test: 55 mL/1.6 sec.
Meets or Exceeds following OE Performance Requirements
OE Approval / Registration
- Cummins CES 14436
- Cummins CES 14439
- Detroit Diesel 93K217
Exceeds OE Performance Requirements
- Cummins Bulletin 3666132
- Cummins CES14603
- Mack
- CAT-EC-1
- Freightliner
- Ford WSS-M97B57-A1/A2
- Paccar CS 0185
- Navistar CEMS B-1, Type IIIA
- Peterbilt
- International
- Kenworth
- John Deere H24
- Komatsu
- John Deere H24 C1
- Komatsu KES 07.892
- John Deere JDS-G135
- Kubota
- Ford WSS-M97-B44D
- GM Heavy Truck
- GM 6277M
- Chrysler/Dodge/Ram
- GMW 34290
- Volvo
- DAF 74002
- Deutz
- MTU
- Hino
- Mitsubishi
- Isuzu
- Waukesha
- Kobelco
- Yanmar
- Scania
- Case New Holland MAT3624
- Mazda
- Iveco
- Hitachi
- Nissan
- Liebherr
- UD
- MAN 324
- Toyota
- Fuso
- Caterpillar
Meets or Exceeds following Industry Standards
- ASTM D6210
- ASTM D3306
- ASTM D4985
- ASTM D7583
- ASTM D4340
- SAE J1941
- TMC RP338A
- TMC RP364
- TMC RP351
- JIS K2234
- SAE J1034
- ASTM D1384.
